Aqualisa Timed Flow Control Kit
Aqualisa Timed Flow Control Kit - Image 2
Aqualisa Timed Flow Control Kit - Image 3
Aqualisa Timed Flow Control Kit - Image 4
Aqualisa Timed Flow Control Kit - Image 5
Aqualisa Timed Flow Control Kit - Image 6
Aqualisa Timed Flow Control Kit - Image 7

Aqualisa Timed Flow Control Kit

Product Description

This Aqualisa Timed Flow Control Kit is single temperature, air-operated solenoid pneumatic valve. Its Runtime is adjustable by the facilities manager and not the end user. The valve comes with 1 meter of tubing and can be mounted up to 3 meters away from the pneumatic push button with additional tubing.

Kit Includes:

  • 1 x Pneumatic Valve
  • 1 x 1.0 Meter Hose
  • 1 x Push Button Assembly

Spec Sheet

Click here to view our specifications.

Click here for all specification sheets and brochures.

SKU: 905101 Category:

Description

Efficient Water Management with Single Temperature Control

The Aqualisa Timed Flow Control Kit features a single temperature air-operated solenoid pneumatic valve, designed for precise water flow control.

Key Features:

  • Adjustable Runtime:
    Facility managers can easily adjust the runtime, ensuring optimal water usage while preventing misuse by end users.
  • Remote Installation:
    The valve can be installed up to 1.0 metre away from the pneumatic push-button, with the option to extend up to 3 metres using additional tubing (available for purchase separately).
  • Versatile Application:
    Ideal for a variety of settings, providing reliable and controlled water flow.

Enhance your water management system with the Aqualisa Timed Flow Control Kit, designed for both efficiency and convenience.

Feature and Benefits

  • Air operated solenoid valve
  • Push Button operation
  • Runtime is adjustable from 5 secs to 5 minutes
  • Factory preset to 30 secs. 12 Month Warranty

Technical Details

  • Inlet/Outlet: DN 15mm BSP
  • Recommended water pressure – 350kpa
  • Max water pressure – 500kpa
  • Max water temperature – 50C
